The HVR-Z1E Video Camera Recorder and the HVR-M10E Videocassette Recorder are two new digital HD products introduced by Sony. They adopt the all-new, 1/4-inch HD format - the HDV 1080i specification of the HDV format - while maintaining the DVCAM/DV recording and playback capabilities provided on current Sony market-acclaimed DVCAM models. Additionally, both the HVR-Z1E and HVR-M10E offer a down-conversion capability of their 1080i recordings, allowing them to be used in current SD systems and providing a step-by-step migration to the HD world. These products are targeted at professional videographers, documentary makers, and feature film makers working on tight budgets. HDV is also an increasingly attractive option for mainstream broadcasters and corporate program makers needing to acquire HD content in restricted or hard-to-reach locations. HDV also serves as an ideal source for contributing HD content into an HDCAM production environment.
This manual covers the HVR‑Z1E video camera recorder and the HVR‑M10E videocassette recorder, both designed for professional videographers, documentary makers, and broadcasters. It explains the HDV 1080i format, down‑conversion capabilities, and how the devices integrate with existing SD and DV workflows.
Key sections describe camera hardware (3‑CCD 1/3‑inch sensors, Carl Zeiss Vario‑Sonnar T* lens, Super SteadyShot), recording and playback formats, audio inputs (built‑in stereo mic and dual XLR with phantom power), power requirements, battery life, and optional accessories such as the wireless remote commander.
| Lens focal length (16:9 mode) | 32.5 mm – 390 mm |
|---|---|
| Filter diameter | 72 mm |
| Recording formats | 1080/50i, 1080/60i, 576/50i (PAL), 480/60i (NTSC) |
| Tape speed (HDV/DV SP) | 18.812 mm/s |
| Maximum playback time (HDV/DV SP) | 63 min |
| Power consumption (HDV playback with LCD on) | 6.5 W |
| Operating temperature | 5 °C to 40 °C |
| Weight | Approx. 1.8 kg |
It supports 1080/50i, 1080/60i, 576/50i (PAL) and 480/60i (NTSC).
