This document describes the usage and precautions of OMRON's ZX-T series SCARA robot programming software. The document also mentions copyright information and disclaimers.
This manual describes how to install the SCARA Studio software for OMRON YRC series robot controllers and explains the major functions available within the program. It also includes safety cautions and references to the robot controller manuals for additional guidance.
The document covers system requirements, installation steps, project creation, editing of programs and parameters, robot operation in manual and auto modes, data backup and restore, and other routine tasks needed to work with SCARA Studio.
| Supported operating systems | Microsoft Windows 2000/XP/Vista |
|---|---|
| 64‑bit support | Not supported |
| Minimum hard‑disk space | 4 MB or more free space |
| Required display | Color monitor supporting VGA or higher resolution |
| Required ports | Serial communication port |
SCARA Studio runs on Microsoft Windows 2000, Windows XP, or Windows Vista; 64‑bit versions are not supported.
You need a CPU that matches the OS, sufficient RAM for the OS, at least 4 MB of free hard‑disk space, a CD‑ROM drive, a serial communication port, and a color monitor that supports VGA or higher resolution.
Use the Data backup function, accessible from the toolbar or the File menu, to back up the controller data.
