The DAC7632 is a 16-bit dual channel voltage output DAC from TI, it supports single or dual supply, the operating temperature range is -40°C to +85°C, it has low power, high accuracy, low noise, and is suitable for industrial process control, data acquisition systems, closed-loop servo control and other applications.
The DAC7632 is a 16‑bit, dual‑channel voltage output digital‑to‑analog converter offering 15‑bit monotonic performance over a –40 °C to +85 °C temperature range. It accepts 24‑bit serial input, features double‑buffered inputs, and supports daisy‑chaining of multiple devices.
The device can be powered from a single +5 V supply or from dual ±5 V supplies, providing output ranges of 0 V to +2.5 V or –2.5 V to 0 V. Low power consumption (4 mW) and fast settling (10 µs to +0.003 % FSR) make it suitable for process control, data acquisition, and closed‑loop servo applications.
| Resolution | 16‑bit dual voltage output |
|---|---|
| Low Power Consumption | 4 mW |
| Settling Time | 10 µs to +0.003 % FSR |
| Supply Voltage Options | Single +5 V or dual ±5 V |
| Output Voltage Range | 0 V to +2.5 V or –2.5 V to 0 V |
The DAC7632 consumes only 4 mW of power.
It settles in 10 µs to within +0.003 % of full‑scale range.
It can be powered from a single +5 V supply or from dual ±5 V supplies.
The device provides an output range of 0 V to +2.5 V or –2.5 V to 0 V.
