MAX410/MAX412/MAX414 is a single/dual/quad low noise low voltage precision op amp launched by MAXIM. This device has a low noise of 2.4nV/√Hz and a low current consumption of 2.5mA, and can operate in a supply voltage range of ±2.4V to ±5V. It also has a 28MHz bandwidth and a maximum slew rate of 4.5V/µs, making it ideal for a wide range of wideband and measurement applications.
The MAX410, MAX412, and MAX414 are single, dual, and quad operational amplifiers that combine ultra‑low voltage‑noise performance with low‑voltage operation. They are available in DIP, SO, and ultra‑small TDFN packages and are suited for applications such as low‑noise frequency synthesizers, infrared detectors, high‑quality audio amplifiers, and ultra‑low‑noise instrumentation.
Key features include a voltage‑noise density of 2.4 nV/√Hz at 1 kHz, a supply current of only 2.5 mA per amplifier, a 28 MHz unity‑gain bandwidth, and a 4.5 V/µs slew rate. The devices operate from ±2.4 V to ±5 V (or 4.8 V to 10 V single‑supply) and provide built‑in back‑to‑back input protection diodes for differential voltages up to ±0.1 V.
| Voltage Noise Density | 2.4 nV/√Hz at 1 kHz |
|---|---|
| Supply Current per Amplifier | 2.5 mA |
| Unity‑Gain Bandwidth | 28 MHz |
| Slew Rate | 4.5 V/µs |
| Output Voltage Swing | 7.3 V P‑P into 2 kΩ |
Each amplifier consumes about 2.5 mA of supply current.
The op‑amp remains stable driving capacitive loads up to 3900 pF.
