This manual provides information on the installation, configuration, operation, maintenance, and troubleshooting of the UDC3200 Universal Digital Controller.
This manual covers the complete lifecycle of the UDC3200 controller, including an overview of the operator interface, detailed installation steps, wiring diagrams, and mounting instructions. It also describes the configuration hierarchy, tuning groups, and communication options such as Modbus RTU and Ethernet TCP/IP.
Additional sections address input and output calibration, alarm setup, safety warnings, and a comprehensive troubleshooting guide. A parts list with exploded views and reference tables for relay contacts, output types, and parameter addresses are also included.
| Relay Contact Type | Electromechanical SPDT contacts (One or Two) |
|---|---|
| Resistive Load Capacity | 5 A @ 120 Vac or 240 Vac or 30 Vdc |
| Current Output Resolution | 14 bits over 0 to 21 mA |
| Maximum Power Consumption | 20 VA (90‑264 Vac) or 15 VA (24 Vac/dc) |
| Maximum Inrush Current | 10 A for 4 ms |
The controller draws a maximum inrush current of 10 A for 4 ms during start‑up.
The current output provides a 14‑bit resolution over 0 to 21 mA with an accuracy of 0.05 % of full scale.
