ADuM3100 is a high-performance digital isolator with enhanced system-level ESD reliability. The device is packaged in an 8-lead SOIC and features low power consumption and high data rates, supporting 3.3 V and 5.0 V operation and level translation. It is suitable for applications such as digital fieldbus isolation, opto-isolator replacement, and computer peripherals.
The ADuM3100 is a digital isolator based on Analog Devices' iCoupler® technology, offering high‑speed CMOS performance with a voltage supply ranging from 3.0 V to 5.5 V, propagation delay under 18 ns, and operation up to 105 °C. It provides low‑power operation (less than 2 mA quiescent) and supports data rates up to 25 Mbps (AR grade) or 100 Mbps (BR grade), with enhanced system‑level ESD protection.
The datasheet includes detailed electrical specifications for 5 V, 3.3 V, and mixed‑voltage operation, package dimensions, pin configurations, safety and insulation ratings, recommended PCB layout, and ordering information. Regulatory approvals such as UL 1577 (2500 V rms) and VDE certifications are also listed.
| Supply Voltage Range | 3.0 V to 5.5 V |
|---|---|
| Propagation Delay | <18 ns |
| Maximum Data Rate | 25 Mbps (AR) / 100 Mbps (BR) |
| Quiescent Current | <2.0 mA (both sides) |
| Maximum Operating Temperature | 105 °C |
| Isolation Voltage (UL) | 2500 V rms for 1 min |
The ADuM3100 supports up to 25 Mbps in the AR grade and up to 100 Mbps in the BR grade.
It operates with a supply voltage ranging from 3.0 V to 5.5 V.
Typical propagation delay is less than 18 ns.
The device is rated for a maximum operating temperature of 105 °C.
