DS90LV017A is a single LVDS driver device manufactured by National Semiconductor. It supports data rates exceeding 600Mbps (300MHz) and has low power consumption. The device is in an 8-lead small outline package and has a flow-through design for easy PCB layout.
The DS90LV017A is a single‑ended LVDS driver optimized for high‑speed data transmission and low power consumption. It supports data rates exceeding 600 Mbps (300 MHz) with a typical differential output swing of 355 mV and includes power‑off protection.
The document provides detailed electrical characteristics, absolute maximum ratings, switching performance, typical performance curves, pin descriptions, and mechanical dimensions, along with a life‑support policy notice.
| Maximum data rate | >600 Mbps (300 MHz) |
|---|---|
| Typical differential output swing | 355 mV |
| Power dissipation (static) | 23 mW @ 3.3 V |
| Operating temperature range | -40 °C to +85 °C |
| Maximum propagation delay | 1.5 ns |
| Typical differential skew | 0.3 ns |
The device supports data rates in excess of 600 Mbps (300 MHz).
The typical differential output swing is 355 mV.
It operates from –40 °C to +85 °C.
Static power consumption is 23 mW at a 3.3 V supply.
