ADC12DL065 is a high-precision analog-to-digital converter (ADC) from Texas Instruments that supports 12-bit digital output.
The ADC12DL065 is a high‑speed dual 12‑bit analog‑to‑digital converter designed for applications such as ultrasound, radar and instrumentation. It operates from a single +3.3 V supply and features a low‑power consumption of 360 mW typical, while delivering up to 65 MSPS conversion rate.
The datasheet provides detailed pin descriptions, absolute maximum ratings, electrical characteristics, and package information (64‑lead TQFP). It also includes application notes on clock isolation, input protection, and layout recommendations to ensure optimal performance.
| Resolution | 12‑bit |
|---|---|
| Maximum Sampling Rate | 65 MSPS |
| Package | 64‑Lead TQFP |
| Operating Temperature Range | -40 °C to +85 °C |
The device is rated for industrial temperature operation from –40 °C to +85 °C.
It is supplied in a 64‑lead TQFP package.
The converter can sample at up to 65 MSPS.
