This is a manual for P5KPL-AM SE ii motherboard
This guide covers everything needed to install and configure the ASUS P5KPL-AM SE motherboard, including safety precautions, hardware layout, and BIOS configuration. It also contains a specifications summary that lists supported processors, memory types, expansion slots, storage options, and I/O ports.
The manual includes detailed BIOS instructions, such as how to set a user password, use the EZ Flash utility, and adjust power and boot settings. Safety information and FCC/Canadian compliance statements are provided to ensure proper handling and regulatory compliance.
| Northbridge chipset | Intel G31 |
|---|---|
| Southbridge chipset | Intel ICH7 |
| Memory slots | 2 x 240‑pin DIMM, unbuffered non‑ECC, up to 4 GB DDR2 |
| Supported memory speeds | 1066 / 800 / 667 MHz DDR2 |
| Expansion slots | 1 × PCI‑Express x16, 1 × PCI‑Express x1, 1 × PCI |
| SATA ports | 2 × SATA 3 Gb/s |
| UltraDMA hard‑disk support | UltraDMA 100 / 66 / 33 |
| USB ports | 8 × USB 2.0 (4 mid‑board, 4 back panel) |
| LAN controller | Realtek RTL8102EL 10/100 |
| Audio codec | 6‑channel ALC662 HD Audio |
Enter the BIOS, select the Change User Password item, type a password of at least six characters, confirm it, and the system will display “Password Installed.”
Disconnect the power cable from the outlet, ensure all cables are unplugged before connecting or removing devices, and read the manual carefully before installation.
The board provides one PCI‑Express x16 slot, one PCI‑Express x1 slot, and one standard PCI slot.
