This is a manual about P5MT-M motherboard, mainly introduces the function features and usage methods of the motherboard
This manual provides step‑by‑step instructions for installing the ASUS P5MT‑M motherboard, including hardware setup, power‑up procedures, BIOS configuration, RAID support and driver installation. It also contains safety information, FCC compliance details and reference diagrams.
The guide is organized into chapters covering product introduction, hardware information, powering up, BIOS setup, RAID support, driver installation and an appendix with reference information such as block diagrams and chipset specifications.
| Supported CPU | Intel® Pentium® Processor Extreme Edition / Intel® Pentium® D / Celeron® |
|---|---|
| System bus speed | 800/1066 MHz |
| Memory slots | 2 × DDR2 533/667 DIMM slots (max 8 GB) |
| Northbridge | Intel® 4‑channel DDR2 533/667 SDRAM controller (Mukilteo, max 8 GB) |
| LAN controller | Broadcom BCM5721 (Rage XL) |
Disconnect the power cable from the outlet before relocating the system and unplug all power cables before adding or removing devices.
The motherboard has two DDR2 533/667 DIMM slots.
The ASUS EZ Flash utility is used for BIOS updates.
The Intel® ICH7R RAID controller driver is supported.
