The LM2742 is a high-performance synchronous switching buck regulator controller that can control currents of 0.7A to 20A with up to 95% conversion efficiencies.
The LM2742 is a high‑speed, synchronous switching regulator controller designed for input voltages from 1 V to 16 V and output voltages adjustable down to 0.6 V. It can handle load currents from 0.7 A to 20 A and offers a selectable switching frequency between 50 kHz and 2 MHz.
The document includes pin descriptions, absolute‑maximum ratings, electrical characteristics, typical performance graphs, and packaging information for the TSSOP‑14 package. Safety and regulatory notes are also provided.
| Input voltage range | 1 V to 16 V |
|---|---|
| Load current range | 0.7 A to 20 A |
| Operating temperature range | -40 °C to +125 °C |
| ESD rating | 2 kV |
| Lead temperature (soldering, 10 s) | 260 °C |
| Package type | TSSOP‑14 |
| Shutdown pin internal pull‑up current | 20 pA |
The LM2742 operates with an input voltage from 1 V to 16 V.
It is intended to control currents ranging from 0.7 A up to 20 A.
The device is rated for temperatures between –40 °C and +125 °C.
