The AD7672 is a high‑speed 12‑bit analog‑to‑digital converter from Analog Devices. It offers selectable unipolar (0‑5 V, 0‑10 V) or bipolar (±5 V) input ranges, operates from +5 V and –12 V supplies, and dissipates only about 110 mW.
Its digital interface provides three‑state data outputs and a 90 ns bus access time, making it easy to connect to modern microprocessors. Various package options are available, including a 0.3‑inch 24‑pin DIP and 28‑pin surface‑mount versions.
| Resolution | 12 bits |
|---|---|
| Power Dissipation (typical) | 110 mW |
| Maximum Power Dissipation | 179 mW |
| Bus Access Time | 90 ns |
| Conversion Time (AD7672XX10) | 10 µs |
| Input Voltage Ranges | 0‑5 V, 0‑10 V, ±5 V |
| Supply Voltage | +5 V and –12 V |
| Package Options | 0.3" 24‑pin DIP, 28‑pin surface‑mount |
The AD7672 provides a 12‑bit resolution.
It can be configured for 0‑5 V, 0‑10 V, or ±5 V input ranges.
The bus access time is 90 ns.
Typical power dissipation is 110 mW.
