PTGD1-LA (Puffer M-UL8E) motherboard features an LGA775 socket, supports Intel® Pentium® 4 processors, and has an Intel® 915P Memory Controller Hub (MCH) and an Intel® ICH6 800 MHz Southbridge. It also has 4 x 184-pin DDR DIMM sockets, which support up to 4 GB of non-ECC DDR SDRAM.
The ASUS PTGD1‑LA (Puffer M‑UL8E) is a Micro‑ATX motherboard featuring an LGA775 socket for Intel® Pentium® 4 CPUs, Intel® 915P northbridge and ICH6 southbridge, and up to 4 GB DDR SDRAM across four DIMM slots. It provides a range of I/O options including USB 2.0, IEEE‑1394a, LAN, audio, and multiple fan connectors.
The manual covers motherboard layout, CPU installation, memory configuration, expansion slots, jumpers, and detailed connector pin‑outs. It also includes BIOS feature notes, fan power ratings, and safety warnings for proper assembly and troubleshooting.
| CPU socket | LGA775 for Intel® Pentium® 4 |
|---|---|
| Southbridge | Intel® ICH6 |
| Memory slots | 4 x 184‑pin DDR DIMM, up to 4 GB non‑ECC DDR SDRAM |
| Expansion slots | 1 x PCI‑Express x16, 3 x PCI |
| LAN controller | Realtek® RTL8101L 10/100Mbps Fast Ethernet |
| Audio codec | Realtek® ALC880 High Definition Audio CODEC |
| Form factor | Micro‑ATX (9.6 in × 9.6 in) |
| Fan connector rating | 350 mA – 740 mA per fan (8.88 W max) or 1 A – 2.22 A total (26.64 W max) at +12 V |
The PTGD1‑LA uses a Micro‑ATX form factor measuring 9.6 in × 9.6 in.
