ASUS DSBV-D User Manual

ASUSTeK COMPUTER INC. published the DSBV-D ii E2661 motherboard manual, which introduces the functions and usage of the motherboard.

Brand: ASUS
Category: Motherboard
Document type: User Manual
Language: English
Pages: 168
File format: PDF
File size: 2.9 MB
Published: 04 May, 2012
Updated: 30 September, 2023
MD5 checksum: 4D1411B94F0BE0235DF958DEE2EFDA66
PDF: ASUS DSBV-D User Manual PDF

About this manual

This manual introduces the ASUS DSBV-D server motherboard, detailing its package contents, special features, and hardware components such as the CPU, memory slots, expansion slots, and connectors. Safety information and FCC compliance statements are also included.

The guide covers system power‑up procedures, BIOS configuration, RAID setup options, driver installation for RAID, LAN, and VGA, and includes block diagrams and reference information for advanced troubleshooting.

What's inside

Product Introduction
Hardware Information
Powering Up
BIOS Setup
RAID Configuration
Driver Installation
Safety Information
Appendix – Block Diagram

Specifications

PCI Express x8 slot (x4 link)	x8 slot (x4 link)
PCI Express x16 slot (x8 link)	x16 slot (x8 link)
DDR2 SO‑DIMM socket	DDR2 SO‑DIMM
PCI/PCI‑X slots	PCI and PCI‑X slots
IDE channel	IDE Channel 0 Master/Slave

Frequently asked questions

How do I install the CPU on the DSBV‑D motherboard?

Refer to section 2.3.1 "Installing the CPU" for step‑by‑step instructions on placing and securing the processor.

How can I configure RAID on the DSBV‑D?

Use the BIOS RAID configuration utilities described in sections 5.1.1 to 5.1.4, then follow the RAID driver installation steps in chapter 5.

What is the procedure to update the BIOS?

The BIOS can be updated using the Phoenix Flash Utility as detailed in section 4.1.2.
