This is a user manual for the P5KPL-AM IN/ROEM/SI motherboard, which introduces the features and characteristics of the motherboard.
This guide explains how to safely install the ASUS P5KPL-AM motherboard, connect power and signal cables, and avoid damage to components. It includes safety warnings, conventions, and step‑by‑step instructions for BIOS configuration and system setup.
The manual also lists the technical specifications of the board, such as chipset, memory support, expansion slots, graphics, storage, networking, audio, and USB ports, and describes BIOS utilities like ASUS EZ Flash 2 and password management.
| Chipset | Northbridge: Intel® G31; Southbridge: Intel® ICH7 |
|---|---|
| Memory | 2x 240‑pin DIMM sockets, unbuffered non‑ECC, up to 4 GB DDR2 |
| Expansion Slots | 1x PCI Express x16 slot, 2x PCI slots |
| Graphics (VGA) | Integrated Intel GMA3100, max resolution 2048 × 15386 @ 75 Hz |
| Storage | 1x UltraDMA 100/66/33 HDD, 2x SATA 150/300 ports |
| LAN | Realtek® RTL8131, 10/100 Ethernet |
| Audio | VT1705 6‑channel high‑definition audio CODEC |
| USB | Maximum 8 × USB 2.0 ports (4 mid‑board, 4 back panel) |
Select the Change User Password item in the BIOS menu and press
Disconnect the power cable from the outlet before moving or working on the system, and ensure all power cables are unplugged before connecting or removing signal cables.
