ASRock M3A780GXH/128M is a motherboard that supports Socket AM3 processors. It features high-quality conductive polymer capacitors, supports processors with a maximum power of 140W, is equipped with AMD 780G + SB710 chipsets, supports overclocking, has a maximum FSB frequency of 2600MHz, supports DDR3 memory with a maximum frequency of 1600MHz, and integrates the AMD Radeon HD 3200 graphics card with support for CrossFire multi-GPU technology.
The ASRock M3A780GXH/128M motherboard supports Socket AM3 processors, including AMD Phenom II and Athlon II series, and features the AMD 780G northbridge with SB710 southbridge. It offers dual‑channel DDR3 memory up to 16 GB and an integrated AMD Radeon HD 3200 graphics processor with up to 512 MB shared memory.
Connectivity includes three PCI Express x16 slots, six SATAII 3.0 Gb/s ports with RAID support, an eSATAII port, Gigabit LAN, HDMI, DVI‑D, and multiple USB 2.0 headers. The board follows the ATX form factor and includes various monitoring and power‑saving features such as Smart BIOS and Instant Boot.
| CPU socket support | Socket AM3, AMD Phenom II X4/X3 (except 920/940), Athlon II X4/X3/X2 |
|---|---|
| Chipset | AMD 780G northbridge + SB710 southbridge |
| Integrated graphics | AMD Radeon HD 3200, DX10 class iGPU, 512 MB shared memory |
| SATA ports | 6 × SATAII 3.0 Gb/s (RAID 0/1/10/JBOD) + 1 × eSATAII |
| LAN | Gigabit Ethernet (10/100/1000 Mb/s) Realtek RTL8111DL |
| Form factor | ATX, 12.0 in × 8.8 in (30.5 cm × 22.4 cm) |
It supports Socket AM3 processors, including AMD Phenom II X4/X3 (except 920/940) and Athlon II X4/X3/X2.
It includes an AMD Radeon HD 3200 graphics processor with DX10 class iGPU and up to 512 MB shared memory.
The motherboard follows the ATX form factor, measuring 12.0 in × 8.8 in (30.5 cm × 22.4 cm).
