The ML2726 is a 2.4GHz 2.0Mbps FSK transceiver operating in the unlicensed 2.4GHz ISM frequency band
The ML2726 is a 2.4 GHz low‑IF FSK transceiver optimized for digital cordless telephone applications. It integrates the PLL synthesizer, voltage regulation, and a 3‑wire control interface, allowing unlimited TX duration and automatic filter alignment.
Key features include a 2.0 Mbps data rate, -80 dBm sensitivity at 0.1 % BER, 3 dBm typical output power, and a Pb‑free 32‑lead TQFP package. Electrical specifications cover a supply range of 2.7 V–4.5 V, standby current of about 10 mA, and carrier frequency coverage from 2.4 GHz to 2.485 GHz.
| Device type | 2.4 GHz Low‑IF 2.0 Mbps FSK Transceiver |
|---|---|
| Typical output power | 3 dBm (differential, typ) |
| Receiver sensitivity | -80 dBm @ 0.1 % BER (typ) |
| Package | 32TQFP 7 mm × 7 mm × 1 mm |
| Supply voltage range | 2.7 V to 4.5 V (VCCA & VDD) |
The typical output power is 3 dBm (differential).
It reaches -80 dBm sensitivity at 0.1 % BER.
It is supplied in a 32‑lead TQFP package measuring 7 mm × 7 mm × 1 mm.
Both VCCA and VDD operate from 2.7 V up to 4.5 V.
