The SPA-1426Z is a 0.7GHz to 2.2GHz 1W InGaP HBT power amplifier from RFMD, which uses InGaP-on-GaAs device technology and MOCVD processing. It has high linearity, low cost, high reliability, and is suitable for use as a driver stage in macro/micro-cell infrastructure equipment or as the final output stage in pico-cell infrastructure equipment.

The RF3809 is a GaAs pre-driver power amplifier, specifically designed for wireless infrastructure applications. Using a highly reliable GaAs HBT fabrication process, this high-performance single-stage amplifier achieves high output power over a broad frequency range. The RF3809 also provides excellent efficiency and thermal stability through the use of a thermally-enhanced surface-mount plastic-slug package. Ease of integration is accomplished through the incorporation of an optimized evaluation board design provided to achieve proper 50 Ω operation. Various evaluation boards are available to address a broad range of wireless infrastructure applications: NMT 450 MHz; GSM850 MHz; GSM9

the rf3807 is a gaas pre-driver power amplifier from rfmd, specifically designed for wireless infrastructure applications

This document describes a cascadable broadband amplifier called NLB-300, which is suitable for general-purpose RF and microwave amplification needs. The amplifier is based on a reliable HBT design, providing a gain of 13.0dB and offering flexibility and stability.

RF2051 is a low power, high performance, wideband RF frequency conversion chip from RFMD, which integrates local oscillator (LO) generation and a pair of RF mixers.

Micro Linear Starter Kits are starter kits designed for beginners and expert radio designers to establish and evaluate a radio link between two Micro Linear transceiver devices. The kits offer features such as frequency agility, high data rate, and strong output power, and provide USB or serial PC communication capabilities.

The ML2726 is a 2.4GHz 2.0Mbps FSK transceiver operating in the unlicensed 2.4GHz ISM frequency band

ML5805 is a 5.8GHz variable data rate FSK transceiver with integrated PA, for 5.725GHz to 5.850GHz unlicensed ISM band

RF3806 GaAs HBT is a GaAs power amplifier from RFMD company, specifically designed for linear applications. This device uses a highly reliable GaAs HBT fabrication process and achieves high output power over a broad frequency range.

The SZP-3026Z is a high-linearity, single-stage, class AB Heterojunction Bipolar Transistor (HBT) power amplifier from RFMD. It is designed with InGaP-on-GaAs device technology and fabricated with MOCVD for an ideal combination of low cost and high reliability. This product is specifically designed for use as a driver or final stage power amp for 802.16 equipment in the 3.0GHz to 3.8GHz bands. It is pre-matched on both ports to simplify external application circuit design. It features an input power detector, on/off power control, ESD protection, excellent overall robust- ness, and a hand reworkable and thermally enhanced surface-mount SOF-26 package.

The SPF-5122Z is a high performance pHEMT MMIC LNA designed for operation from 50MHz to 4000MHz. It offers ultra-low noise figure and high linearity performance in a gain block configuration. Its single-supply operation and integrated matching networks make implementation remarkably simple.

The RF3377 is a general purpose, low-cost RF amplifier IC. The device is manufactured on an advanced Gallium Arsenide Heterojunction Bipolar Transistor (HBT) process, and has been designed for use as an easily-cascadable 50Ω gain block. Applications include IF and RF amplification in wireless voice and data communication products operating in frequency bands up to 6000MHz. The device is self-contained with 50Ω input and output impedances and requires only two external DC-biasing elements to operate as specified.

RF3397 is a low-cost, general purpose RF amplifier IC from RF Micro Devices. The device is manufactured on an advanced Gallium Arsenide Heterojunction Bipolar Transistor (HBT) process, and has been designed for use as an easily-cas- cadable 50Ω gain block. Applications include IF and RF amplification in wireless voice and data communication products operating in frequency bands up to 6000MHz.
