This document describes the features and characteristics of the MFD−CP8 display for the MFD−80−B model, as well as the connection to the power supply unit/communication module. It also provides a download link for the emulation software required for commissioning.
The Moeller MFD-80-B is a compact display/keypad unit designed for industrial control applications. It features a clear LCD display, optional emulation software for commissioning, and a range of mounting options.
The document provides detailed specifications such as weight, dimensions, operating temperature range, IP protection rating, and compliance with IEC/EN standards. Environmental and electromagnetic compatibility requirements are also listed to aid proper installation and use.
| Mounting plate thickness | 1–6 mm |
|---|---|
| Storage temperature | -25 °C to +55 °C |
| Dimensions (L × W × H) | 28.25 mm × 30 mm × 20.2 mm |
The unit measures 28.25 mm × 30 mm × 20.2 mm.
