This is a CMEL OLED module specification. It describes the product's characteristics in detail, including driving mode, color mode, driver IC, interface, application scenario, etc.
This document provides the preliminary product specification for the Densitron C0240QGLH‑T OLED display module. It outlines the purpose, general description, driving mode, color mode, interface options, and intended applications such as cell phones.
Key sections include mechanical dimensions, absolute maximum ratings, DC and AC electrical characteristics, CPU interface timing for M68 and M80, reliability test procedures, and package information. The specification is intended for designers to reference when integrating the module into products.
| Diagonal Size | 24" |
|---|---|
| Resolution | 240 xRGB x320 |
| Pixel Pitch | 0.051%0.153 mm |
| Active Area | 36.72%48.96 mm |
| Outline Area | 42*58.6 mm |
| Thickness | 2.75 mm (typ) |
| VGH (Gate High Voltage) | -3.0 V |
| VGL (Gate Low Voltage) | -6.0 to -3.0 V |
| VINT (Internal Voltage) | -40 to -1.0 V |
| Logic Operating Voltage (RVDD) | 1.45‑1.55 V |
| Power Supply Voltage 1 (VDD3) | -0.3 to +5.0 V |
| Power Supply Voltage 2 (VCcI) | -0.3 to +5.0 V |
| Input Voltage Range (Vin) | -0.3 to VDD+0.5 V |
| Operating Temperature | -20 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
The display has a 24‑inch diagonal.
Both VDD3 and VCcI may range from –0.3 V to +5.0 V.
The module operates from –20 °C up to +60 °C.
The pixel pitch is 0.051%0.153 mm.
