AD7466/AD7467/AD7468 are 1.8V to 3.6V micro-power 8/10/12-bit ADCs with features including low power consumption, fast throughput rate, wide input bandwidth, and compatibility with multiple interfaces. They are suitable for applications such as battery-powered systems, medical instruments, and remote data acquisition.
The AD7466/AD7467/AD7468 family are low‑power successive‑approximation ADCs available in 8‑, 10‑, and 12‑bit versions. They operate from a single 1.8 V to 3.6 V supply and achieve up to 100 kSPS throughput while consuming less than 1 mW in normal mode. The devices are offered in compact 6‑lead SOT‑23 and 8‑lead uSOIC packages.
Key features include a wide input bandwidth, flexible power/clock management, standby mode current of 0.5 pA, and a high‑speed serial interface compatible with SPI, QSPI, I²C, and DSP buses. Typical applications are battery‑powered systems, medical instruments, and isolated data acquisition.
| Supply Voltage Range | 1.8 V to 3.6 V |
|---|---|
| Resolution | 8/10/12 bits |
| Throughput Rate | 100 kSPS |
| Standby Mode Current | 0.5 pA max |
| Power‑Down Current | 0.5 µA max |
| Input Voltage Range | 0 to Vpp |
| Signal‑to‑Noise Ratio (SNR) | 71 dB min (AD7466) |
| Signal‑to‑Noise‑and‑Distortion Ratio (SINAD) | 70 dB min (AD7466) |
| Total Harmonic Distortion (THD) | -78 dB typ (AD7466) |
The devices can operate up to 100 kSPS.
Standby mode draws a maximum of 0.5 pA.
They are offered in a 6‑lead SOT‑23 package and an 8‑lead uSOIC package.
The analog input range is 0 to Vpp.
