This document is about ADP3307's specification, including features such as 0.8% accuracy, ultra-low dropout, low static current, and multiple fixed voltages
The ADP3307 anyCAP™ linear regulator provides high‑accuracy voltage regulation with a typical dropout of 120 mV at 100 mA and a low shutdown current of 1 pA. It operates from a 3.0 V to 12 V supply range and includes current‑limit, thermal‑shutdown and error‑flag functions for robust performance.
Designed for space‑constrained applications, the device is stable with any type of output capacitor, including MLCCs, requiring only 0.47 µF for stability. Typical applications include cellular phones, notebook computers, battery‑powered systems, bar‑code scanners, camcorders and other portable electronics.
| Line Regulation | 0.02 mV/V |
|---|---|
| Load Regulation | 0.06 mV/mA |
| Typical Dropout Voltage (100 mA) | 120 mV |
| Shutdown Current | 1 pA |
The typical dropout voltage is 120 mV at a load current of 100 mA.
The shutdown current is 1 pA.
It operates from 3.0 V to 12 V.
