This document is about the standard microcircuit drawing requirements at the Defense Supply Center Columbus. The document includes information on lead finish, absolute maximum ratings, and other specifications.
This drawing defines the scope, applicable standards and detailed requirements for the 28F010 128 K × 8 CMOS flash EEPROM and related device classes. It includes device class designators, case outlines, lead finishes, and the part‑identifying number (PIN) format used for procurement and certification.
Technical tables provide absolute maximum ratings, recommended operating conditions, electrical performance characteristics, and capacitance values. Vendor CAGE numbers and approved sources are listed, along with certification and compliance requirements for military‑grade microcircuits.
| Supply voltage range | -2.0 V to +7.0 V |
|---|---|
| Maximum power dissipation | 1.0 W |
| Input leakage current | ≤ 1.0 pA |
| Output leakage current | ≤ 10 pA |
| Input capacitance | 10 pF (typical) |
| Output capacitance | 12 pF (typical) |
The device operates with a supply voltage from –2.0 V up to +7.0 V.
The maximum power dissipation is 1.0 W.
