This document is a DCDC power supply specification parameter table, which provides information such as the input and output voltage range, output power, efficiency, input current, rated current, etc. of the power supply.
The SP-150 series provides 150 W single‑output power supplies with active PFC (PF > 0.93) and a range of selectable output voltages from 3.3 V to 48 V. Each model includes protections such as short‑circuit, overload, over‑voltage and over‑temperature, and optional remote ON‑OFF control.
Key specifications include a universal AC input (85 – 264 VAC), high efficiency up to 84 % (typ), ripple and noise ≤ 100 mV p‑p, and compliance with safety standards UL60950‑1 and EN55022. The units are compact (199 × 99 × 50 mm) and weigh 0.76 kg, with a three‑year warranty.
| Input Voltage Range | 85 – 264 VAC |
|---|---|
| Power Factor (typ.) | PF > 0.93 @230 VAC |
| Dimensions | 199 × 99 × 50 mm (L × W × H) |
| Weight | 0.76 kg |
| Warranty | 3 years |
The SP-150 series accepts a universal AC input from 85 V to 264 V.
It provides short‑circuit, overload, over‑voltage, over‑temperature protection and a constant current limiting circuit.
The unit operates from –10 °C to +60 °C.
