AD Series Switch Power Supply Manual

User Manual 1 pages · 139 KB · JA

The AD series switch power supply delivers up to 155 W with a fixed 134 kHz switching frequency. It supports a wide input voltage range and includes protections such as short‑circuit, over‑current, and over‑temperature.

The unit complies with international safety standards (UL, CUL, TUV, CB, CE) and operates from –10 °C to 50 °C, with derating at higher temperatures. Mechanical dimensions, packaging, and detailed electrical performance data are listed for each output voltage option. This manual is written in Japanese.

Covers: Specifications · Safety Certifications · Electrical Characteristics · Mechanical Dimensions · Performance Data · Operating Temperature

MW medical series30W A single set of output Without housing medical Type Meanwell opening power supply Manual

Product Leaflet 1 pages · 134 KB · JA

The MPS-30 series is a compact, low‑leakage medical power supply designed for use in hospital equipment. It offers a range of output voltages from 5 V to 48 V with high efficiency and built‑in protection features such as short‑circuit, overload, and over‑temperature protection.

Key data include an input voltage range of 88‑264 VAC (120‑370 VDC), leakage current below 0.3 mA, dimensions of 101.6 × 65.8 × 23.5 mm, and a weight of 0.16 kg per unit. The product complies with safety standards UL2601‑1, IEC60601‑1, EN60950‑1, and others relevant to medical devices. This manual is written in Japanese.

Covers: Specifications · Input Voltage · Output Options · Safety Standards · Dimensions · Weight and Packaging

650W Power Supply Module Manual

User Manual 1 pages · 151 KB · ZH

The document describes the 650W power supply module series, covering its design features such as ZVS technology, internal PFC, and short‑circuit protection. It outlines compliance with standards like EN61000‑3‑2, UL60950‑1 and EN550022 class B, and lists the available output voltages and current ratings.

Technical details include input voltage range, operating temperature limits, dimensions, and warranty information. The manual also provides wiring diagrams, connector types, and recommended cooling methods for reliable operation. This manual is written in Chinese.

Covers: Features · Technical Specifications · Installation · Operation · Safety and Compliance · Warranty

MINGWEI G3 Switch Power Supply Manual

User Manual 1 pages · 377 KB · JA

This manual describes the MINGWEI G3 series 25 W built‑in switch power supply. It includes safety information, compliance with international standards such as UL60950‑1 and EN550022 class B, and outlines the device's protection features.

The document lists electrical characteristics, including an input voltage range of 88‑264 VAC, selectable output voltages (3.3 V, 5 V, 12 V, 15 V, 24 V, 48 V) with corresponding current limits and efficiencies, and an operating temperature range of –20 °C to +70 °C. This manual is written in Japanese.

Covers: Safety and Compliance · Input Voltage Range · Output Voltage Options · Operating Temperature · Efficiency and Current Ratings · EMC and Standards
