The Philips HeartStart OnSite Defibrillator is a device that can restore normal heart rhythm in the event of sudden cardiac arrest (SCA). It provides a fast and effective treatment, delivering necessary shocks to SCA victims within five minutes of collapse. Using this device can significantly improve the survival rate of SCA victims.
The HeartStart OnSite Defibrillator is a lightweight, ready‑to‑use automated external defibrillator designed for anyone to operate in an emergency. Weighing just 3.3 lb (1.5 kg) and featuring clear voice prompts, SMART Pad cartridges, and Quick Shock technology, it helps responders deliver a shock quickly and perform CPR with coaching.
This manual covers unpacking, self‑tests, step‑by‑step use, maintenance, battery and pad replacement, and detailed technical specifications. It also includes program‑management guidance for organizations that deploy multiple units.
| Dimensions (DxHxW) | 2.8" × 7" × 8.3" (7 cm × 19 cm × 21 cm) |
|---|---|
| Operating temperature range | 32 °F – 122 °F (0 °C – 50 °C) |
| Standby temperature range | 50 °F – 109 °F (10 °C – 43 °C) |
| Adult defibrillation peak current | 32 A (150 J nominal) |
| Shock‑to‑Shock cycle time | < 20 seconds |
| Quick Shock delivery time | ≈ 8 seconds after CPR interval |
| Battery type | 9 V DC, 4.2 Ah lithium manganese‑dioxide primary cells |
The defibrillator operates between 32 °F and 122 °F (0 °C – 50 °C).
It can deliver a shock in about 8 seconds after the CPR interval.
The device ships with a replaceable SMART Pads cartridge containing adult adhesive pads; infant/child pads are optional.
