TP0610K Vishay Siliconix is a new product of P-channel 60V (D-S) MOSFET, with low on-resistance, low threshold, fast switching speed, low input capacitance, gate-source ESD protection, ease in driving switches, low offset (error) voltage, low-voltage operation, high-speed circuits, etc. It can be used to drive relays, solenoids, lamps, hammers, displays, memories, transistors, etc. It is also suitable for battery operated systems, power supply converter circuits, and solid state relays.
The TP0610K is a P‑channel MOSFET designed for high‑side switching applications. It features a low typical on‑resistance of 6 mΩ, a low threshold voltage around –2 V, fast switching speed (≈20 ns), and integrated gate‑source ESD protection up to 2000 V.
Typical applications include drivers for relays, solenoids, lamps, and other low‑voltage, high‑speed circuits. The device is supplied in a TO‑236 (SOT‑23) surface‑mount package and is suitable for battery‑operated systems, solid‑state relays, and power‑supply converter circuits.
| Drain‑Source Voltage (VDS) | -60 V |
|---|---|
| Gate‑Source Voltage (VGS) | +20 V |
| On‑Resistance (RDS(on)) | 6 mΩ (typ) |
| Gate Threshold Voltage (VGS(th)) | -2 V (typ) |
| Total Gate Charge (Qg) | 17 nC |
| Input Capacitance (Ciss) | 23 pF |
The TP0610K can withstand a drain‑source voltage of up to –60 V.
The typical on‑resistance is 6 mΩ.
Yes, it has gate‑source ESD protection rated at 2000 V.
