This document provides information on the safe use of Kyocera LCD modules.
The TCGI04VG2ZAA-G00 is a 640 × 480 dot amorphous‑silicon TFT transmissive color LCD with side‑edge CFL backlight, intended for audio control, office automation, industrial control and home appliances. The module includes optional inverter (CXA‑0308, TDK) and a glare‑treated polarizer.
The datasheet details mechanical dimensions, absolute maximum ratings, electrical characteristics, timing requirements and inspection standards, allowing designers to integrate the display safely and reliably into their products.
| Outline dimensions | 243 mm × 185.1 mm × 10.5 mm |
|---|---|
| Effective viewing area | 213.2 mm × 160.4 mm |
| Dot number | 640 × 480 |
| Dot pitch | 0.11 mm × 0.33 mm |
| Power input voltage (VDD) | 0.3 V – 6.0 V |
| Operating temperature | -10 °C to 70 °C |
| Storage temperature | -20 °C to 80 °C |
| Typical power supply voltage | 3.3 V (typical) |
| Typical power supply current | 450 mA |
The recommended inverter is CXA‑0308 (TDK).
The module is rated for operation from –10 °C to 70 °C.
The typical supply voltage is 3.3 V (with a range of 3.0 V to 5.0 V).
The LCD has a resolution of 640 × 480 dots.
