This document provides the full specification for the Kyocera KHS057QVICJ-G01 LCD module, intended for use in audio control, office automation, industrial control, and home appliances. It includes application notes, construction details, and a complete set of mechanical, electrical, and optical parameters.
Key sections cover absolute maximum ratings, supply voltage requirements, timing charts, backlight characteristics, and inspection standards, allowing designers to integrate the module safely and reliably into their products.
| Outline dimensions (W x D) | 154.6 mm x 114.8 mm |
|---|---|
| Dot size | 0.10 mm |
| Dot pitch | 0.12 mm |
| Mass | 200 g |
| Supply voltage for logic (VDD) typical | 5.00 V |
| LCD driving voltage (VEE) typical | 25.6 V |
| Current consumption (IDD) typical | 4.5 mA |
| Power consumption (Pdisp) typical | 330 mW |
| Operating temperature range | 0 °C to 50 °C |
| Maximum supply voltage for LCD driving (VEE) | 33.0 V |
The maximum supply voltage for the LCD driving circuit (VEE) is 33.0 V.
The module is rated to operate from 0 °C up to 50 °C.
The module measures 154.6 mm in width and 114.8 mm in depth.
