TL(BG,RP)A1100(T11) is a surface-mount LED lamp from Toshiba. It measures 3.2 (L) × 2.9 (W) × 1.9 (H) mm and is available in blue green and reddish purple colors. It can operate in temperatures ranging from -40 to 100 degrees Celsius and is suitable for use in automotive applications, backlighting, and more.
The TL(BG,RP)A1100(T11) series are surface‑mount LED devices with UVLED chip + RGB phosphor, offered in bluish‑green (TLBGA1100) and reddish‑purple (TLRPA1100) colors. The document lists electrical characteristics such as forward voltage (typical 3.5 V) and reverse current (typical 0.75 µA), optical data including luminous intensity (typical 100 mcd) and chromaticity coordinates, and maximum ratings.
Packaging is an aluminum envelope with silica gel and a moisture‑indicator card. Recommended storage before soldering is 5 °C–30 °C with humidity up to 90 % (sealed) or 60 % RH after opening, and baking procedures are described for moisture‑affected devices. Soldering guidelines, cleaning solvent recommendations, and handling precautions are also provided.
| Luminous Intensity (typ) TLBGA1100 | 100 |
|---|---|
| Chromaticity x (typ) TLBGA1100 | 0.15 |
| Weight (typ) | 0.035 g |
They are packed in an aluminum envelope with silica gel and a moisture‑indicator card.
