This Quick Start Guide introduces the features and functions of the Zoom i.MX LITEKIT and explains how to install and use the product.
The QuickStart Guide introduces the Zoom i.MX LITEKIT development kit, describing its main features such as the SOM‑LV module, LCD display connector, audio, USB, Ethernet, and expansion headers. It explains how to unpack the kit, the contents included, and the required development PC specifications.
The guide then walks through hardware connections, power‑up procedures, sample applications, jumper and switch settings, and where to obtain technical support, warranty information, and additional resources such as FAQs and discussion groups.
| Baseboard dimensions | 158.8 mm x 146.1 mm x 17.1 mm |
|---|---|
| i.MX31 SOM‑LV dimensions | 76.2 mm x 59.1 mm x 7.9 mm |
| i.MX27 SOM‑LV dimensions | 76.2 mm x 50.8 mm x 7.9 mm |
| USB interfaces | One USB 2.0 high‑speed host, One USB 2.0 high‑speed On‑the‑Go device |
| Ethernet connector | One RJ45 Ethernet jack with magnetics |
