The MCF5213EC is a 32-bit microcontroller from Freescale, based on the V2 ColdFire core and supporting up to 256Kbytes of flash and 32Kbytes of SRAM
The MCF5213 is a 32‑bit ColdFire® microcontroller built on the Version 2 core, running up to 80 MHz. It integrates up to 256 KB of flash memory, 32 KB of SRAM, a FlexCAN controller, three UARTs, I²C, QSPI, an eight‑channel 12‑bit ADC, DMA, timers and a programmable watchdog.
The document provides a detailed block diagram, electrical characteristics, mechanical package outlines (64‑pin LQFP, 64‑pin QFN, 81‑pin MAPBGA, 100‑pin LQFP), and a full list of pin functions and signal descriptions for designers and software developers.
| Core frequency | up to 80 MHz |
|---|---|
| Flash memory | up to 256 KB |
| SRAM | 32 KB |
| ADC | 8‑channel, 12‑bit |
| UARTs | 3 |
| FlexCAN module | CAN 2.0B controller |
| DMA controller | Four channels |
| Interrupt sources | 57 |
The processor can run at frequencies up to 80 MHz.
It includes up to 256 KB of on‑chip flash memory.
The device contains three universal asynchronous/synchronous UARTs.
The ADC provides 12‑bit resolution across eight channels.
