GF 467F is a function generator from Codico, with a frequency range of 0.01Hz to 5MHz, internal linear or logarithmic sweep, support VCF or FM modulation and AM modulation.
The GF467F is a function generator offering a frequency range from 0.01 Hz to 5 MHz across eight selectable ranges. It supports internal linear or logarithmic sweeps, external VCF or FM modulation, AM modulation, and a CMOS offset function. Waveforms include sine, triangle, square, ramp and impulse, with adjustable duty cycle from 20 % to 80 % and low distortion (<1 %).
The unit features a protected BNC output (up to +60 V reverse surges), 20 V p‑p open‑circuit output level, 50 Ω output impedance, and selectable attenuation (0, –20 dB, –40 dB). It includes a 5‑digit red LED frequency display, RS‑232 interface via a 9‑pin SUB‑D connector, and a 230 V AC mains supply with 30 VA maximum consumption. Safety compliance follows EN standards with IP31 protection rating.
| Frequency range | 0.01 Hz to 5 MHz (8 ranges) |
|---|---|
| Fixed attenuation | 0 dB, –20 dB, –40 dB (switchable) |
| Power consumption | 30 VA max |
| Interface | RS‑232, 9‑pin male SUB‑D connector |
The GF467F covers 0.01 Hz to 5 MHz across eight selectable ranges.
