The PDF file provides instructions and features of the Canon ZOOM 518 and ZOOM 318 Super 8 cameras. These cameras incorporate the new Super 8 system, featuring easy film loading and focusing.
This manual explains how to load Super 8 film, operate the shutter, focus, and adjust exposure on the Canon Zoom 518 and 318 cameras. It describes the built‑in color‑conversion filter, automatic film‑speed setting, and basic handling steps.
The specifications section lists the camera type, lens details, viewfinder, power requirements, dimensions, weight, and available accessories such as the trigger grip and optional tele‑converter for the 518 model.
| Camera type | 8 mm cine camera, Super 8 film cartridge |
|---|---|
| Frame size | 4 × 5.4 mm (Super 8 film) |
| Lens focal length (Zoom 518) | 9.5 – 47.5 mm |
| Lens focal length (Zoom 318) | 10 – 30 mm |
| Zoom ratio (Zoom 518) | 1 : 5 |
| Zoom ratio (Zoom 318) | 1 : 3 |
| Viewfinder | Parallax‑free single‑lens reflex, 4 prisms, 11‑element lens |
| Exposure meter | Through‑lens CdS meter, batteries two 1.3 V #625 |
| Film sensitivity (ASA) | 25 – 160 (16 – 100 with filter) |
| Filming speed | 18 fps |
| Power for drive | Three 1.5 V penlight batteries |
| Dimensions (Zoom 518) | 206 × 101 × 44 mm |
| Weight (Zoom 518) | 1,020 g |
| Dimensions (Zoom 318) | 204 × 101 × 44 mm |
| Weight (Zoom 318) | 1,015 g |
Insert a Super 8 film cartridge into the camera as shown in the loading steps.
The drive uses three 1.5 V penlight batteries, while the exposure meter is powered by two 1.3 V #625 batteries.
The Zoom 518 lens zooms from 9.5 mm to 47.5 mm (1 : 5 ratio).
No, a tele‑converter is not available for the Zoom 318 model.
