The AD8002 is a dual channel 600MHz, 50mW current feedback amplifier. It features excellent video specifications, low power consumption, high speed and fast settling, and high output drive capability. It is suitable for applications such as A/D drivers, video line drivers, differential line drivers, professional cameras, video switchers, special effects, and RF receivers.
The AD8002 is a dual, low‑power, high‑speed current‑feedback amplifier designed for +5 V supplies. It offers excellent video specifications, low distortion, and fast settling, making it suitable for professional video equipment, high‑speed A‑to‑D drivers, and portable battery‑powered applications.\n\nKey features include a 600 MHz –3 dB bandwidth at unity gain, 1200 V/µs slew rate, 16 ns settling time to 0.1 %, over 70 mA output drive, and operation over a +3 V to +6 V supply range. The device is available in 8‑lead plastic DIP, SOIC, and uSOIC packages.
| Bandwidth (‑3 dB) at G=+1 | 600 MHz |
|---|---|
| Slew Rate | 1200 V/µs |
| Settling Time to 0.1 % | 16 ns |
| Maximum Output Current | Over 70 mA |
| Supply Current per Amplifier | 5.5 mA (55 mW) at +5 V |
| Operating Supply Voltage Range | +3 V to +6 V |
The AD8002 provides a 600 MHz –3 dB bandwidth at gain = +1.
The device can deliver over 70 mA of output current.
It operates from +3 V to +6 V supply voltage.
