The AD828 is a low-cost, dual video op amp optimized for use in video applications that require gains of +2 or greater and high output drive capability, such as cable driving.
The AD828 is a low‑cost, dual video operational amplifier optimized for video applications that require gains of +2 or greater and high output‑drive capability. It operates from single‑supply (+5 V) or dual‑supply (+5 V to +15 V) configurations, drawing only 15 mA supply current while delivering up to 50 mA per amplifier.
The datasheet provides extensive performance data, including a 130 MHz 3 dB bandwidth at a gain of +2, 450 V/µs slew rate, 2 mV input offset voltage, and excellent differential gain and phase errors (0.01 %). Typical application circuits such as video line drivers and low‑distortion amplifiers are illustrated, along with detailed pin‑outs and package dimensions.
| 3 dB Bandwidth (G = +2) | 130 MHz |
|---|---|
| Slew Rate | 450 V/µs |
| Quiescent Supply Current | 15 mA |
| Output Current per Amplifier | 50 mA (minimum) |
| Input Offset Voltage | 2 mV |
| Differential Gain Error | 0.01 % |
| Power Supply Range | +5 V to +15 V |
| Input Resistance | 300 kΩ |
Each amplifier can source a minimum of 50 mA output current.
The device draws a maximum of 15 mA supply current.
The AD828 provides a 130 MHz 3 dB bandwidth at a gain of +2.
The typical input offset voltage is 2 mV.
