The AD8017 is a low cost, dual high speed amplifier capable of driving low distortion signals to within 1.0 V of the supply rail. It is intended for use in single supply xDSL systems where low distortion and low cost are essential. The amplifiers will be able to drive a minimum of 200 mA of output current.
The AD8017 is a low‑cost, dual high‑speed amplifier capable of delivering up to 200 mA per output while maintaining low distortion. It operates from a 5 V to 12 V supply and draws only 7 mA per amplifier, making it ideal for single‑supply xDSL CPE equipment.
The device is offered in an 8‑lead SOIC package (Thermal Coastline) with options for tape‑and‑reel packaging. It operates over a commercial temperature range of –40 °C to +85 °C and includes built‑in ESD protection.
| -3 dB Bandwidth | 160 MHz |
|---|---|
| Slew Rate | 1600 V/µs |
| Supply Current per Amplifier | 7 mA |
| Operating Temperature Range | -40 °C to +85 °C |
| Typical Output Current | 200 mA |
The AD8017 draws 7 mA per amplifier from a 5 V to 12 V supply.
It operates from –40 °C to +85 °C.
The device can source or sink up to 500 mA when the output is shorted, but the specified short‑circuit current rating is 1500 mA.
The AD8017 is offered in an 8‑lead SOIC (Thermal Coastline) package, with tape‑and‑reel options for both 13‑inch and 7‑inch reels.
