AD8005 is an ultralow power, high-speed amplifier. It features ultralow power consumption, high bandwidth, low distortion/noise, etc. It is suitable for signal conditioning, A/D buffering, power-sensitive high-speed systems, battery-powered equipment, communication or video test systems, portable medical instruments, etc.
The AD8005 is a current‑feedback amplifier designed for power‑sensitive, high‑speed systems. It offers a 270 MHz –3 dB bandwidth (gain = +1), 280 V/µs slew rate, and ultralow quiescent current of 400 pA at a +5 V supply, enabling long battery life without sacrificing performance.
The device is supplied in 8‑lead plastic DIP, 8‑lead SOIC and 5‑lead SOT‑23 packages and operates over an industrial temperature range of –40 °C to +85 °C. Typical applications include signal‑conditioning for A/D buffers, portable medical instruments, communication/video test systems, and other battery‑powered high‑speed equipment.
| Bandwidth (‑3 dB) | 270 MHz (gain = +1) |
|---|---|
| Quiescent Current | 400 pA |
| Operating Temperature Range | -40 °C to +85 °C |
| Input Voltage Noise (10 MHz) | 4.0 nV/√Hz |
The AD8005 draws 400 pA of quiescent current at a +5 V supply.
It is offered in 8‑lead plastic DIP, 8‑lead SOIC, and 5‑lead SOT‑23 packages.
The device operates from –40 °C up to +85 °C.
The –3 dB bandwidth is 270 MHz when the gain is set to +1.
