Introduces the use of Microchip 16-Bit 28-Pin Starter Development Board
This guide introduces the 16‑Bit 28‑Pin Starter Development Board, describing its hardware features, power options, UART‑to‑USB communication, LED indicators, and on‑board peripherals. It explains how to connect the board to the MPLAB ICD 2 debugger and outlines the required software tools.
The manual includes a step‑by‑step tutorial for creating and building a project, programming the dsPIC33F device, and running the demonstration program. Appendices provide schematics, board layout drawings, and a bill of materials, while warranty registration and recommended reading sections point users to additional Microchip resources.
| Microcontroller | dsPIC33F |
|---|---|
| Pin Count | 28 pins |
| Processor Architecture | 16‑bit |
| Power Supply Options | 5 V or 3.3 V jumper selectable |
| UART Interface | UART‑to‑USB |
| LED Indicators | Multiple status LEDs |
| External Stimulus Switches | Two user‑programmable switches |
| Device Clocking | Configurable clock source |
| Debug Interface | MPLAB ICD 2 in‑circuit debugger |
Complete the enclosed Warranty Registration Card and mail it promptly.
Visit the Microchip website at www.microchip.com for the most up‑to‑date files and information.
The board is used with the MPLAB ICD 2 in‑circuit debugger.
