This data sheet details the features and characteristics of the PIC16C5X series, including 33 single-word instructions, single-cycle instructions, 200-nanosecond instruction cycle, 18 to 28 pins, 12 to 20 I/O ports, 384 to 2048 bytes of EPROM/ROM, and 25 to 73 bytes of RAM.
The PIC16C5X family from Microchip Technology is a low‑cost, high‑performance 8‑bit CMOS microcontroller series that uses EPROM or ROM program memory. It employs a RISC core with 33 single‑word instructions, all executing in a single 200 ns cycle, and offers a range of oscillator options and power‑saving modes.
The document includes detailed pin diagrams for PDIP, SOIC and SSOP packages, electrical characteristics for each device variant, memory organization tables, I/O port descriptions, Timer0 module information, special CPU features, the full instruction set summary, and packaging data. It also provides ordering information and references to development tools and programming services.
| Number of instructions | 33 single‑word instructions |
|---|---|
| Instruction cycle time | 200 ns |
| Maximum clock input | 20 MHz |
| Typical current consumption @5 V, 4 MHz | < 2 mA |
| Program memory (PIC16C52) | 384 × 12‑bit words |
| EPROM voltage range (commercial/industrial) | 2.0 V to 6.25 V |
The PIC16C52 package offers 18 I/O pins.
ROM devices operate from 2.0 V to 6.25 V for commercial/industrial applications and 2.5 V to 6.0 V for extended temperature ranges.
