tps28xx series are dual high-speed mosfet drivers, capable of delivering 2a peak current to drive high capacitive loads. the series employs a true zero-switching design, which provides high switching speed and reliable drive performance in high-voltage and high-frequency applications. the tps28xx drivers include an internal regulator, which allows operation with supply inputs between 14v and 40v.
The TPS2811‑TPS2815 series are dual high‑speed MOSFET drivers that deliver up to 2 A peak output current and include an internal regulator for operation from 8 V to 40 V. They are offered in 8‑pin PDIP, SOIC and TSSOP packages and operate over a temperature range of –40 °C to 125 °C.
The document provides absolute maximum ratings, recommended operating conditions, electrical characteristics, switching performance, mechanical dimensions and regulatory notices. It also lists the available package options and pin functions for each driver variant.
| Peak Output Current | 2 A |
|---|---|
| Supply Voltage Range (Voc) | 4 V – 14 V |
| Regulator Input Voltage Range | 8 V – 40 V |
| Operating Temperature Range | -40 °C – 125 °C |
| Supply Current (Input High or Low) | 5 A |
| Package Options | 8‑pin PDIP, SOIC, TSSOP |
| Dissipation Rating (P package) | 1090 mW |
The drivers can deliver a peak output current of 2 A.
The regulator input voltage range is 8 V to 40 V.
The devices operate from –40 °C up to 125 °C.
They are offered in 8‑pin PDIP, SOIC, and TSSOP packages.
