Motorola MPC564EVB User Manual

MPC564EVB user's manual, introduces the use of MPC564EVB

Brand: Motorola
Category: Cell Phones
Document type: User Manual
Language: English
Pages: 98
File format: PDF
File size: 1.6 MB
Published: 02 May, 2012
Updated: 01 October, 2023
MD5 checksum: AF7ED117B2AD972ECCAC966C7D11709F
PDF: Motorola MPC564EVB User Manual PDF

About this manual

This manual describes the MPC564EVB development board, a hardware platform intended for educational or professional laboratory use. It covers board hardware, memory configuration, connectors, and supported communication ports.

The document includes detailed instructions for initializing the system, using the dBUG monitor/debug firmware, and troubleshooting network and other operational issues.

What's inside

MPC564 EVB Board
System Memory
Support Logic
Communication Ports
Connectors and User Components
Initialization and Setup
Using the Monitor/Debug Firmware
Troubleshooting Network Problems

Specifications

EMC Class	Class A (meets EN5022 and EN 50082-1)
Reference Frequency	66 MHz references added

Frequently asked questions

What is the intended use of the MPC564EVB board?

The board is designed as a development platform for hardware or software in an educational or professional laboratory.

What safety precautions should be taken when using the board?

Anti‑static precautions must be followed, and users should avoid modifying cables or wiring that could affect performance or cause interference.
