ASRock 4CoreDual-SATA2 Motherboard User Manual

4CoreDual-SATA2 User Manual

Brand: ASRock
Category: Motherboard
Document type: User Manual
Language: Chinese
Pages: 51
File format: PDF
File size: 653 KB
Published: 02 May, 2012
Updated: 30 September, 2023
Model: 4COREDUAL-SATA2
MD5 checksum: 8A7553A9C8AA9018FCB51C2EA92BFD7D
PDF: ASRock 4CoreDual-SATA2 Motherboard User Manual PDF

About this manual

This manual covers the complete hardware installation process for the ASRock 4CoreDual-SATA2 ATX motherboard, including CPU, memory, expansion slots, and connector wiring. It also details BIOS configuration options, supported operating systems, and the contents of the support CD.

Additional sections describe minimum hardware requirements, supported PCI Express graphics cards, SATA hot‑plug features, and safety cautions for over‑clocking and battery disposal. This manual is written in Chinese.

What's inside

Introduction
Installation
BIOS Setup Utility
Software Support
Specifications
Minimum Hardware Requirements
Supported PCI Express VGA Card List
SATA II Hard Disk Setup
Overclocking Cautions
Contact Information

Specifications

Form Factor	ATX (12.0" x 9.6")
Chipset	Northbridge VIA PT880, Southbridge VIA VT8237S
SATA Connectors	2 x Serial ATAII 3.0 Gb/s (RAID 0/1/JBOD, hot‑plug)

Frequently asked questions

How many SATA ports are available and do they support RAID?

The board provides two Serial ATAII connectors that support RAID 0, RAID 1, JBOD and hot‑plug operation.
