The CASIO DT-X7 is a small, light and fast hand terminal. It is equipped with Windows® CE® 5.0 operating system, integrated laser scanner, WLAN, Bluetooth®, infrared, voice recorder and QVGA color display, and also has IP54 dust and water protection.
The Casio DT-X7 is a compact, ultra‑light mobile terminal designed for one‑hand operation in retail, POS, and warehouse environments. Its ergonomic S‑shaped hand terminal, balanced weight of about 145 g, and IP54 dust‑ and water‑proof rating enable fatigue‑free, long‑duration use.
The device includes a high‑performance laser scanner with 0.127 mm resolution, a 2.4‑inch QVGA colour display, 64 MB RAM, and multiple wireless interfaces (Bluetooth 2.0, IrDA 1.3, WLAN 802.11b/g). Power is supplied by interchangeable lithium‑ion batteries with up to 26 hours runtime, and the unit meets industrial protection standards such as 1 m drop resistance and IP54.
| Operating system | Windows CE 5.0 |
|---|---|
| Memory (RAM) | 64 MB |
| Flash ROM | 64 MB |
| Display size | 2.4 inch QVGA colour LCD |
| Display resolution | 240 × 320 pixels (65,536 colours) |
| Scanner resolution | 0.127 mm |
| Scan range | 40‑400 mm |
| Large battery capacity | 1880 mAh, approx. 17 h runtime |
| Protection rating | IP54 (dust and water) |
| Drop protection | 1.0 m |
| Operating temperature | -10 °C to +50 °C |
| Dimensions (L × W × H) | 166 × 52 × 23.5 mm |
| Weight | ≈ 145 g (with standard battery) |
The device weighs approximately 145 g with the standard battery installed.
It can operate from –10 °C up to +50 °C.
The laser scanner has a resolution of 0.127 mm and can read barcodes from 40 mm to 400 mm away.
