The ASRock WiFi-802.11n module is an easy-to-use wireless local area network (WLAN) adapter that supports WiFi+AP functionality. It allows you to easily create a wireless environment and enjoy the convenience of wireless network connectivity. You can play LAN games, connect to the internet, access and share printers, and make internet phone calls from anywhere within the signal range. Please read this operation guide carefully before setting up the ASRock WiFi-802.11n module.
This guide explains how to install the ASRock WiFi-802.11n module on a compatible motherboard, connect the antennas, and install the driver and utility software. It also details system requirements, hardware mounting, and the use of the ASRock WiFi‑802.11n Wizard for quick configuration.
The document describes the two operating modes—Access Point (AP) and Station (Infrastructure or Ad‑hoc)—and provides step‑by‑step instructions for setting up each mode, selecting security options, and troubleshooting common issues.
| Standard | IEEE 802.11n |
|---|---|
| Data Rate | 15, 30, 45, 60, 90, 120, 135, 150 Mbps |
| Security | AES, TKIP, WEP |
| Frequency Band | 2.4 GHz ISM |
| Indoor Operating Range | 330 ft (100 m) |
| Outdoor Operating Range | 980 ft (300 m) |
| Maximum Connected Devices (AP mode) | up to 16 stations |
| Antenna | omni‑directional |
| LED Indicator | Green data transmission (AIR) |
The module can support up to 16 stations in AP mode.
The indoor range is up to 330 ft (100 m).
Open the wizard from the taskbar icon, select “Create a wireless access point”, configure the SSID and security settings, then finish the wizard.
