This document introduces the PIC16C7X series of 8-bit CMOS microcontrollers with A/D converters. The microcontrollers have high performance, low power consumption, and are easy to use.
The PIC16C7X family is a low‑cost, high‑performance 8‑bit CMOS microcontroller line that includes integrated 8‑bit analog‑to‑digital converters, multiple timers, PWM, and serial communication modules. It offers a wide operating voltage range, on‑chip watchdog timer, sleep mode, and up to eight‑level deep hardware stack, making it suitable for a variety of embedded applications.
The document contains detailed pin diagrams for various packages, a full table of contents covering architecture, memory organization, peripheral modules, electrical characteristics, and packaging information, as well as appendices on compatibility and product identification. Technical tables list program memory sizes, data memory, I/O pins, and other key specifications for each device variant.
| Program Memory | up to 8K × 14‑word EPROM |
|---|---|
| Data Memory (RAM) | up to 368 bytes |
| Operating Voltage Range | 2.5 V – 6.0 V |
| Timer Modules | 3 |
| Hardware Stack Depth | 8 levels |
The PIC16C74 has 192 bytes of data memory.
The on‑chip A/D converter provides 8‑bit resolution.
In‑Circuit Serial Programming (ICSP) is supported.
