This document introduces Microchip's various development tools, including simulator, compiler, programmer, debugger, demonstration board and evaluation board
The Development Tools Ordering Guide provides an overview of Microchip's development systems, including MPLAB ICE 2000 and ICE 4000 emulators, programmer kits, demo boards, and evaluation kits. It lists product families, key features, and ordering part numbers for each tool.
The guide also includes contact information for worldwide sales and service locations, on‑line support details, and warranty and upgrade policies for Microchip development products.
| Emulation Speed | Full Speed Real‑Time Emulation |
|---|---|
| Low Voltage Range (ICE 2000) | 2.0 V to 5.5 V |
| Trace Memory (ICE 2000) | 32K × 128‑bit |
| Programmable Clock (ICE 2000) | 32 kHz to 40 MHz |
| Low Voltage Range (ICE 4000) | down to 1.8 V (or device limit) |
| Trace Memory (ICE 4000) | 64K × 216‑bit |
The ordering part number for the MPLAB ICE 2000 is ICE2000.
It supports low‑voltage emulation from 2.0 V to 5.5 V.
The MPLAB ICE 4000 provides 64K deep by 216‑bit wide trace memory.
