DS30275A is a high-performance RISC microcontroller with 35 single-word instructions, fast operation speed, wide operating voltage range and low power consumption.
The PIC16C77X family includes 28‑pin (PIC16C773) and 40‑pin (PIC16C774) devices offering a high‑performance RISC CPU, up to 14 interrupt sources, and a range of on‑chip peripherals such as timers, PWM, A/D converter, and serial interfaces. The devices operate from 2.5 V to 5.5 V and support in‑circuit serial programming.
Key features include 4 KB of 14‑bit program memory, 256 bytes of RAM, a 12‑bit multi‑channel ADC, and low‑power modes. Detailed electrical characteristics, pin‑out diagrams, and packaging information are provided throughout the document.
| Operating speed | DC - 20 MHz clock input |
|---|---|
| Instruction cycle time | 200 ns |
| Program memory | 4 K × 14‑bit words |
| Data memory (RAM) | 256 × 8 bytes |
| Interrupt sources | up to 14 internal/external |
| Operating voltage range | 2.5 V to 5.5 V |
| Sink/Source current | 25 mA each |
| Low‑power consumption | <2 mA @5 V, 4 MHz |
The device operates up to a DC‑20 MHz clock input.
The family is offered in 28‑pin and 40‑pin packages.
Each device provides 4 KB of 14‑bit program memory.
It operates from 2.5 V to 5.5 V.
