The ISP1362 is a single-chip Universal Serial Bus (USB) On-The-Go (OTG) controller integrated with the advanced NXP Slave Host Controller and the NXP ISP1181B Peripheral Controller.
The ISP1362 is a single‑chip USB On‑The‑Go (OTG) controller that integrates a slave host controller and a peripheral controller. It supports full‑speed (12 Mbit/s) and low‑speed (1.5 Mbit/s) USB transfers and can operate as either a host or a peripheral, with one configurable OTG port and a second downstream‑only port.
The device is offered in 64‑pin LQFP and TFBGA packages, runs from a 3.3 V supply, and operates from –40 °C to +85 °C. It provides up to 14 programmable endpoints, 4 KB of multiconfiguration memory, and a 16‑bit parallel interface capable of 10 MB/s data transfer to a host processor. Typical applications include mobile phones, digital cameras, MP3 players and other portable devices that require USB OTG functionality.
| Full‑speed data rate | 12 Mbit/s |
|---|---|
| Low‑speed data rate | 1.5 Mbit/s |
| Operating voltage | 3.3 V |
| Operating temperature range | ‑40 °C to +85 °C |
| Package types | 64‑pin LQFP and TFBGA |
| Number of USB ports | 2 |
| Programmable USB endpoints | up to 14 |
| Integrated configuration memory | 4096 bytes |
| Microprocessor‑to‑device data rate | 10 MB/s |
It supports full‑speed at 12 Mbit/s and low‑speed at 1.5 Mbit/s.
The controller operates from a 3.3 V power supply.
The device provides two USB ports; port 1 is configurable as downstream, upstream or OTG, while port 2 is downstream‑only.
It can operate from –40 °C up to +85 °C.
