The P82B96 is a dual bidirectional I2C bus buffer, featuring isolation capacitance, 400kHz operation, 2V~15V supply voltage range, low power supply current, ESD protection and low power consumption.
The P82B96 is a bipolar integrated circuit that provides a non‑latching, bi‑directional interface between I²C buses and other bus configurations. It supports supply voltages from 2 V to 15 V, offers 60 mA sink capability on Tx/Ty outputs, and includes ESD protection exceeding 3500 V.
The document lists features, typical applications, pin configurations, ordering information, maximum ratings, and detailed electrical characteristics. It also contains revision history and packaging options (DIP, SO, TSSOP).
| Tx/Ty output sink capability | 60 mA |
|---|---|
| ESD protection | ≥ 3500 V HBM |
| Package types | DIP, SO, TSSOP |
| Maximum input capacitance per pin | 7 pF |
Each Tx/Ty output can sink up to 60 mA, suitable for low‑impedance or high‑capacitance buses.
The IC includes ESD protection exceeding 3500 V HBM per JESD22‑A114.
The part is offered in DIP, SO, and TSSOP packages.
